Faster Printing: 4-laser-synchronous printing technology, up to 60% faster than previous system
High Precision: ±0.1 mm dimensional accuracy and premium surface finish with crisp detail
Large Format: 800 × 800 × 550 mm build volume, accommodating both large parts and small batch production
Smart Manufacturing: UT-ONE remote monitoring system supports batch management of multiple devices and data insights
| Build Volume | 800 × 800 × 550 mm |
| Layer Thickness | 0.05-0.25 mm |
| Accuracy | L<100 mm: ±0.1 mm, L ≥100 mm: ±0.1% x L |
| Laser | 4 Lasers, Solid-state Triple Frequency Nd:YVO4 |
| Beam Size | 0.12-0.9 mm |
| Scanning Speed | 2.5-12.8 m/s |
| Control Software | RSCON |
| Part Preparation Software | PolydevsPro, BPC |
| Temperature Range | 22 – 26 ℃ |
| Relative Humidity | ＜ 40% |
| Resin Vat Capacity | 560 kg, replaceable |
| Electrical Requirements | 200-240 VAC, 50/60 Hz, 5.9 kVA |
| Printer Dimensions | 2045 × 1965 × 2475 mm (H collapses to 2100 mm for transport) |
| Printer Net Weight | 1693 kg |
| Certificates | CE-MD certified by TÜV SÜD |
Consult with your sales representative for confirmation of current offering.
